Name: ATH Single Lift® 12PL
SKU: 8053
Price: 620000 ISK
Availability: OutOfStock

ATH Single Lift® 12PL

620.000 kr.

The ATH Single Lift® 12PL is an electrohydraulic single-post lift with a 1,200 kg capacity, a quick-lift power unit and a load-dependent lowering function. Designed for stationary use, it features a reinforced column and a robust platforms design. Extra-long, adjustable platforms enable multifunctional vehicle pick-up. Optional wheel forks expand the range of applications and provide flexible solutions for everyday workshop use

⇒PRODUCT FLYER

⇒3D / AR

Out of stock

Description

Product highlights

Electro-hydraulic 1-post lift with quick lift unit and load-dependent lowering function

Central control unit with energy set (230V / compressed air / 12V)

Stationary use, with reinforced column and rail construction

Safety Control: Electromagnetic release of the safety locks automatically with lifting and lowering

Safety Lock: ability to lock the load on to the safety mechanism

Multifunctional mounting via sliding, extra long rails and wheel forks (optional)

Ideally suited for repairing quads, lawn mowers and small tractors

Product details

Rated load capacity	1200 kg
Lifting height max.	1930 mm
Overall width	1900 mm
Overall height	3140 mm
Support arms parts	1 St.
Driving power	3 kW
Lifting/Lowering time	20 \| 20 s
Power supply voltage	3x 400V / C16A
Concrete strength	C 25/30 2500 x 2000 x 200
Color	RAL 7016 / RAL 9005
