Description

NAV PHONE FOR THE MOTORCYCLE, DONE RIGHT!

Looking for a phone sized Android device for navigation that just ticks all the right boxes? Well you found it.

This IP67 device is optimised for navigation and was developed to be easily attached to your motorcycle.

A 6″ Android 12 device with Google certification, regular OTA updates, Octa-Core CPU, 64GB internal memory + removable storage available for DMD2 maps and user files.

With a magnetic (with holding clips) AMPS bolt pattern charging base that allows you to quickly attach and detach it and was tested on tough enduro rides (supports additional screws that lock phone and base)!

Includes DMD2 pre-installed with life-time license, certified and optimised!

Many motorcycle quality of life features like auto turn-on, configurable auto turn-off, ignition detection, gloves mode and extra configurable DMD2 function hardware button.

The magnetic charging base can be connected to a motorcycle specific power supply with ignition detection or to an USB plug.

SPECIFICATIONS:

Octa Core Processor		Android 12		OTA Updates
161.5mm L x 77.5mm W x 14.5mm D		280g		5.7inch, IPS panel 1140×720 800 nit
Capacitive multi-touch / Glove, Wet		Battery 3.7V 4000mAh		Dual-SIM card slot
64GB eMMC Storage + optional removable SD		micro SDXC card slot		USB Type C (2.0) (OTG)
4G-LTE TDD:B40,B38,B41		GNASS, GLONASS, GALILEO, A GPS		Wifi 5GHz: 802.11a/n/ac — up to 500 Mbps;
Rear: 16MP Autofocus Front: 8MP Fixed Focus		USB or RS232 (default with docking station)		BT v2.1+EDR, 3.0+HS, v4.1+HS
Light sensor & Proximity sensor		IP67		Accelerometer, E-Compass, Gyroscope



FIXATION BRACKETS

If your motorcycle has a 12mm bar:
– Use the DMD AMPS Base + Super Amps Converter
– Not enough clearance – most motorcycles like BMW GS / Tenere 700 – will require a 12mm extension bracket like these: 12mm bracket with AMPS base or Our special edition 12mm bracket with AMPS base

If you want to mount it on the handlebar:
– Use our shortest 28mm handlebar AMPS bracket  (For 28mm handlebar only) + Super Amps Converter
– Or to place the device closer to you use our 22-28mm handlebar long bracket (For 22 and 28mm handlebar)

For the KTM 890/790 (19-22) / KTM 390 / HUSQVARNA NORDEN:
– Use our specific mount and AMPS converter

For the KTM 890/790 (2023+):
– Use our specific mount + we also recommend adding the Super Amps Converter

Extra recommendation for Yamaha Tenere 700:
– Please make sure you have a cockpit anti-vibration bracket like this one

Already got an AMPS mount but need to convert orientation or screw direction?:
– Check out our Super AMPS Converter
